Example Projects

List of photovoltaic (PV) Projects

The lists given below (through hyperlinks) are not meant to be exhaustive. For the list of examples of government-funded projects, some smaller projects and latest projects are not included. For the list of examples of non-government projects, it is compiled from the Survey on Renewable Energy Installations, which started in late 2006, along with information gathered from other sources.

The Survey on Renewable Energy Installations is an on-going exercise. The survey questionnaire can be downloaded from the main page of Example Projects.

Some of the PV projects are described below, with photos.

EMSD Headquarters PV Installations

A 350 kW photovoltaic (PV) installation has been installed on the roof of the New EMSD Headquarters in Kowloon Bay. This installation comprises a solar array made up of more than 2,300 PV modules which together has a total area of around 3,180 m2, and a smaller system made up of PV glass laminates.

Each PV module in the solar array is constructed in the form of a rectangular panel and consists of 72 series-connected mono-crystalline silicon PV cells. The panels are mounted on supporting racks in an inclined manner and facing southwards so as to receive maximum solar irradiation during the year.

In addition to these, PV glass laminates are installed on the viewing gallery on the roof of the building. There are totally 20 sets of PV glass laminates, each consisting of 100 series-connected mono-crystalline PV cells sandwiched between two sheets of glass.

The d.c. output of the installation is converted into a.c. by a number of inverters. The a.c. power generated by the PV installation supplements the electricity supply from the power company to meet the electrical power requirement of the building.

EMSD Headquarters PV Installations. The text above describes the image.


Hong Kong Housing Authority's Public Housing Estates Solar Lamps and PV Installations

Solar lamps and PV installations have been installed in various public housing estates of the Hong Kong Housing Authority.  Please click the link below for details.

Link:   This web page has hyperlinks which may transfer you to third-party website.http://www.housingauthority.gov.hk/hdw/en/aboutus/ events/greenestate/sec4_7_1.html

Science Park Building-integrated PV Installations

Building-integrated PV installations (grid-connected) have been installed on nine buildings in the Science Park. Total capacity of all the installations is 198 kW.

Science Park Building-integrated PV Installations. The text above describes the image.


Wanchai Tower PV Installation

The Wanchai Tower PV Installation (grid-connected) consists of three subsystems - Rack Type Subsystem on the roof, Sunshade Screen Type Subsystem outside windows, and Skylight Type Subsystem at the entrance hall. Total capacity is 55 kW.

Rack Type Subsystem. The text above describes the image.
Above: Rack Type Subsystem

Sunshade Screen Type Subsystem. The text above describes the image.
Above: Sunshade Screen Type Subsystem

Skylight Type Subsystem. The text above describes the image.
Above: Skylight Type Subsystem


Kowloon Hospital PV Installation

The Kowloon Hospital PV Installation is grid-connected and was announced in July 2007.  Peak capacity of the system is 9 kW.

Kowloon Hospital PV Installation. The text above describes the image.


Hong Kong Science Museum PV Installation

The PV Installation in Hong Kong Science Museum is grid-connected and was installed in August 2007.  Peak capacity of the system is 10 kW.

 Hong Kong Science Museum PV Installation. The text above describes the image.


Airport Police Station PV Installation

The PV Installation in Airport Police Station is grid-connected and was installed in November 2007.  Peak capacity of the system is around 16 kW.

Airport Police Station PV Installation. The text above describes the image.


Chek Lap Kok Fire Station

The Chek Lap Kok Fire Station PV Installation is grid-connected and was installed in 2008.  Peak capacity of the system is 16 kW.

Chek Lap Kok Fire Station. The text above describes the image.


Tseung Kwan O Hospital

The PV Installation in Tseung Kwan O Hospital is grid-connected and was installed in 2008. Peak capacity of the system is around 9 kW.

Tseung Kwan O Hospital. The text above describes the image.


Hong Kong Museum of Coastal Defense

The PV installation in the Hong Kong Museum of Coastal Defense is grid-connected and was installed in 2008. It was made up of 60 nos. of PV panels. Peak capacity of the system is around 7.8kW.

Hong Kong Museum of Coastal Defense. The text above describes the image.


Hong Kong Museum of Art

The PV installation in the Hong Kong Museum of Art is grid-connected and was installed in 2008.

Hong Kong Museum of Art. The text above describes the image.


Shatin Park and Kowloon Park

6 sets of solar powered LED bollard lamps and 10 sets of solar powered LED bollard lamps were installed in the Aviary Garden of Shatin Park and the roof garden in Kowloon Park respectively in 2008.

Shatin Park. The text above describes the image.

 Kowloon Park. The text above describes the image.

Tuen Mun Town Hall

Solar-powered LED lamp poles were installed at Tuen Mun Town Hall in 2008.

Tuen Mun Town Hall. The text above describes the image.


Kowloon Hospital (West Wing)

The PV Installation in Kowloon Hospital (West Wing) is grid-connected and was installed in 2008. Peak capacity of the system is around 18 kW.

 Kowloon Hospital (West Wing). The text above describes the image.

Marsh Road Station Building

The grid-connected PV Installation in Marsh Road Station Building was installed in September 2008.  Peak capacity of the system is around 2.8 kW.
(Source: The Hongkong Electric Co., Ltd.)

The grid-connected PV Installation in Marsh Road Station Building. The text above describes the image.


The Prince Philip Dental Hospital

The PV Installation in the Prince Philip Dental Hospital is grid-connected and was installed in 2009. Peak capacity of the system is around 3.68 kW.

The Prince Philip Dental Hospital. The text above describes the image.


Hong Kong Park

Solar lamps were installed in Hong Kong Park in 2009.

Hong Kong Park. The text above describes the image.

Building integrated photovoltaic system was installed in Hong Kong Park in 2009. The capacity of the system is 2.4kW.

Building integrated photovoltaic system. The text above describes the image.


PV Installation in Tsim Sha Tsui Promenade

The PV Installation in Tsim Sha Tsui Promenade is grid-connected and was installed in 2009. Peak capacity of the system is around 2.2 kW.

PV Installation in Tsim Sha Tsui Promenade. The text above describes the image.


Sai Kung Outdoor Recreation Centre

Solar powered lamps were installed in Sai Kung Outdoor Recreation Centre in 2009.

Sai Kung Outdoor Recreation Centre. The text above describes the image.


Kwai Tsing Theatre

Solar powered lamps were installed in Kwai Tsing Theatre in 2009.

Kwai Tsing Theatre. The text above describes the image.


PV Installation in Cloudridge Quarters

The PV Installation in Cloudridge Quarters is grid-connected and was installed in 2009. Peak capacity of the system is 5.25 kW.

PV Installation in Cloudridge Quarters. The text above describes the image.


Shau Kei Wan Government Secondary School

3.3kW grid-connected amorphous silicon thin film PV system installed on the roof of school building in 2010.

Shau Kei Wan Government Secondary School. The text above describes the image.


Chiu Lut Sau Memorial Secondary School

3.15kW grid-connected amorphous silicon thin film PV system installed on the roof of school building in 2010.

Chiu Lut Sau Memorial Secondary School. The text above describes the image.


Yuen Long Government Primary School

3.2kW grid-connected amorphous silicon thin film BIPV system installed at the cover of the walkway on ground floor playground in 2010.

Yuen Long Government Primary School. The text above describes the image.


South Yuen Long Government Primary School

1.5kW grid-connected amorphous silicon thin film BIPV system installed on the canopy of school building entrance in 2011.

South Yuen Long Government Primary School. The text above describes the image.



CLP Power’s Renewable Energy Generation System at Town Island

A standalone renewable energy (RE) generation system in Town Island located at the east of Hong Kong was completed in October 2012.  The system consisted of 180kW solar panels and 2 nos. of 6kW wind turbines operated in parallel providing electricity to residents in the Island.  For further information about the system, please make reference to the webpage below:

www.clpgroup.com/poweru/eng/town_island/ technology_everyLittleSteps.aspx
